Functions: Power reverse connection protection, dry running protection, stall protection, overvoltage protection, etc.
* Customizable: Sheath model, pin definition, bracket, outlet length, and label format.
| Pump Series | Series | Rated Voltage | Rated Power | Inlet/Outlet Dia | Rated Conditions | Control Method | Protection |
|---|---|---|---|---|---|---|---|
| 8 series | 802 series | DC24V | 1050W | Φ38mm | 15M/12000L/H | PWM/CAN | IP67 |
| 862 series | DC24V | 600W | Φ38mm | 20M/42000L/H | PWM/CAN | IP67 |
1. Orientation: The water pump must be installed with its axis horizontally.
2. Location: Install in low temperature or air flow-friendly locations, as far away from high temperature areas as possible.
3. Proximity: Install as close to the cooling water tank as possible to reduce water inlet resistance.
4. Height: Installation height should be more than 500mm from the ground, and lower than the height of the water tank to facilitate pipeline exhaust and medium circulation.
A specialized provider dedicated to the import and export of new energy vehicle parts. Main products include electronic accelerator pedals, electronic water pumps (Low-voltage/High-voltage), electric heaters, insulation monitors, gear controllers, and hoses. With more than 30 national patent certificates, the independent production plant focuses on designing, researching, developing, and manufacturing new energy vehicle electronics. We provide custom-made auto parts to precisely fit different vehicle models according to specific needs. Products are distributed across Asia, Europe, the Americas, and Africa.
